Duitse standaard autokabel - FHLR2XBC2X (dunne wand)


Productieproces:
Geleider: blank koperdraad, vertind koperdraad
Isolatie: Halogeenvrije, verknoopte polyolefine-isolatie
Afscherming: gevlochten koperdraad
Verpakking: aluminium-plastic tape
Mantel: Halogeenvrij verknoopt polyolefine omhulsel
Temperatuurbereik: –40°C ~ 125°C
Standaard: ISO 19642
Nominale spanning: AC 600 V / DC 900 V
Milieuvereisten: Voldoet aan RoHS en REACH
Referentienorm: ISO 19642, LV216
Toepassingen:​
Halogeenvrij, vlamvertragend, olie- en verouderingsbestendig. Geschikt voor EV-hoogspanningskabelbomen, elektronische bedieningselementen en veiligheidsbedrading in voertuigen.

Onderzoek nu
  • Model Specificatie Aantal kernen Dirigent Isolatie Vertinde koperen vlecht Schede Maximale DC-weerstand van een geleider bij 20°C
    Dirigent – Conductor Construction Dirigent – Min. Thickness (mm) Isolatie Range Diameter Gemiddelde dikte Schede Range Blank koper Vertind koper Vernikkeld koper
    mm mm Min Max Max mm Max Min Ω/km
    FHL2X/91X 1.5 1 30/0,25 0.24 2.2 2.4 0.13 0.4 3.4 3.7 12.7 13 13.2
    FHL2X/91X 2 1 40/0,25 0.28 2.5 2.8 0.13 0.4 3.7 4.1 9.42 9.69 9.82
    FHL2X/91X 2.5 1 50/0,25 0.28 2.7 3 0.13 0.4 3.9 4.3 7.6 7.82 7.92
    FHL2X/91X 3 1 44/0,30 0.32 3.1 3.4 0.16 0.4 4.2 4.8 6.15 6.39 6.41
    FHL2X/91X 4 1 56/0,30 0.32 3.4 3.7 0.16 0.4 4.5 5.1 4.71 4.85 4.91
    FHL2X/91X 5 1 70/0,30 0.32 3.9 4.2 0.16 0.6 5.4 6 3.94 4.02 4.11
    FHL2X/91X 6 1 84/0,30 0.32 4 4.3 0.16 0.6 5.5 6.1 3.14 3.23 3.27
    FHL2X/91X 8 1 112/0,30 0.32 4.6 5 0.19 0.65 6.5 7.1 2.38 2.52 2.6
    FHL2X/91X 10 1 322/0,20 0.48 5.3 6 0.19 0.65 7.5 8.1 1.82 1.85 1.9
    FHL2X/91X 12 1 385/0,20 0.48 5.8 6.5 0.19 0.65 8 8.6 1.52 1.6 1.66
    FHL2X/91X 16 1 511/0,20 0.52 6.4 7.2 0.19 0.8 9 9.6 1.16 1.18 1.21
    FHL2X/91X 20 1 646/0,20 0.52 7 7.8 0.19 0.8 9.6 10.2 0.955 0.999 1.03
    FHL2X/91X 25 1 798/0,20 0.52 7.9 8.7 0.21 0.9 10.7 11.3 0.743 0.757 0.774
    FHL2X/91X 30 1 950/0,20 0.64 8.7 9.6 0.21 0.9 11.6 12.2 0.647 0.684 0.706
    FHL2X/91X 35 1 1121/0,20 0.64 9.4 10.4 0.21 1 12.6 13.2 0.527 0.538 0.549
    FHL2X/91X 40 1 1273/0,20 0.71 10 11.1 0.21 1 13.3 13.9 0.473 0.5 0.516
    FHL2X/91X 50 1 1596/0,20 0.71 11 12.2 0.21 1.1 14.6 15.2 0.368 0.375 0.383
    FHL2X/91X 60 1 1924/0,20 0.8 12 13.3 0.21 1.1 15.5 16.3 0.315 0.333 0.344
    FHL2X/91X 70 1 2220/0,20 0.8 13 14.4 0.21 1.1 16.6 17.4 0.259 0.264 0.27
    FHL2X/91X 85 1 2701/0,20 0.9 14.4 15.8 0.26 1.1 18.2 19 0.219 0.225 0.228
    FHL2X/91X 95 1 3034/0,20 0.9 15.3 16.7 0.26 1.1 19.1 19.9 0.196 0.2 0.204
